The SZL double drum water tube steam boiler is horizontal type water tube boiler, the combustion equipment is chain grate. The boiler adopts fast assembly or packaged assembly structure, boiler with steam capacity lower than 4t/h is fast assembly water tube structure, boiler with steam capacity between 4~35t/h is consisted of upper part (boiler heated part) and lower part(combustion equipment). The wood fired steam boiler has the advantages of compact structure, high steam quality, sufficient output, operate convenient and environmental protection.
Structure of 20 ton per hour Coal Fired Steam Boiler
Assembly of boiler body and combustion equipment separately;
With long and short drum drum structure;
Use front and rear arch structure to promote heat transfer;
Double-sided independent air intake structure;
Conservative grate area, Long burning time of coal;
Light insulation insulation material, and steel plate molding;
The boiler room is a single floor;
Advantage of 20 ton per hour Coal Fired Steam Boiler
Easy installation on site;
Increased a large number of convective heating surfaces;
Enhance the adaptability of coal;
Guaranteed combustion effect;
Improve boiler thermal efficiency;
Simple and elegant appearance;
Short construction period and low cost;
